Customized PCB FPC Antena Inner Ethernet Internal Patch Built In Pcb Antenna esp32 Wifi Dipole PCB External 2.4ghz Antenne
Ready to Ship
In stock Fast dispatch

Customized PCB FPC Antena Inner Ethernet Internal Patch Built In Pcb Antenna esp32 Wifi Dipole PCB External 2.4ghz Antenne

  • 100 - 499 Pieces
    $0.35
  • 500 - 999 Pieces
    $0.32
  • >= 1000 Pieces
    $0.30

Customization:

Frequency（Min.Order: 1000 pieces）
Gain（Min.Order: 1000 pieces）
View product details

Customized PCB FPC Antena Inner Ethernet Internal Patch Built In Pcb Antenna esp32 Wifi Dipole PCB External 2.4ghz Antenne

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • Multi-Band Wireless Connectivity: Supports 2.4GHz and 5GHz frequency ranges for high-speed Wi-Fi, Bluetooth, and IoT communication, enabling seamless integration into smart devices.
  • Versatile Design: Built-in PCB antenna with vertical polarization and 50Ω impedance ensures optimal signal performance in compact spaces, ideal for ESP32-based systems and other embedded applications.

Key features

  • 1. Material Technology

    • With flexible PCB construction, you can seamlessly integrate the antenna into compact devices, offering 30% thinner profiles than rigid alternatives*.

  • 2. Interactive Design

    • With a UFL connector, you can achieve quick and secure connections, reducing installation time by up to 40% compared to SMA connectors*.

  • 3. Performance Parameters

    • With a 2.4–5GHz frequency range and 50W max input power, you can support high-speed Wi-Fi and Bluetooth while handling 50% higher power loads than standard antennas*.

  • 4. Scenario Solutions

    • With optimized signal reception across urban/rural environments, you can maintain strong connectivity in diverse settings, outperforming generic antennas by 25% in signal strength*.

  • 5. Certification Standards

    • With FCC/CE certification, you can ensure regulatory compliance for global deployment, avoiding compatibility issues faced by uncertified alternatives.

Product details

Customized PCB FPC Antena Inner Ethernet Internal Patch Built In Pcb Antenna esp32 Wifi Dipole PCB External 2.4ghz Antenne

The Customized PCB FPC Antenna is a versatile wireless communication solution designed for integration into compact electronic devices like smartphones, IoT modules, and routers. Built with flexible PCB material, it supports 2.4GHz and 5GHz frequencies, ensuring reliable signal transmission for Wi-Fi, Bluetooth, and cellular networks. Its UFL connector and 50Ω impedance guarantee seamless compatibility with ESP32 and other microcontroller systems.

Technical specifications

FeatureSpecificationApplication Scenario
Frequency Range2400–2500 MHz (2.4GHz), 5GHz*Wi-Fi 6, Bluetooth 5.0+, and IoT device networking
Impedance50ΩEnsures optimal power transfer in PCB circuits
MaterialFlexible PCB (FPC)Enables conformal design for space-constrained devices
Max Input Power50W (Pro Model)Industrial-grade applications with high-power transmitters
PolarizationVerticalReduces interference in vertically oriented devices
Connection TypeUFL ConnectorQuick integration with ESP32 and MCU boards

*5GHz support available in Advanced/Pro models.

Customization guide

Adjustable parameters include:

  • Frequency tuning (2.4GHz/5GHz bands) to match specific regulatory standards.
  • Antenna shape/size for optimal signal directionality in compact enclosures.
  • Material thickness to balance flexibility and durability for rugged environments.

Get inspired

With its modular FPC design, this antenna simplifies integration into wearables, drones, and smart home devices. Its vertical polarization ensures stable signal alignment in vertical device orientations, while the 50W power capacity handles high-throughput industrial IoT systems.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Frequency Range2.4GHz2.4GHz + 5GHz2.4GHz + 5GHz
Max Input Power25W40W50W*
Impedance Stability±15%±10%±5%
Material Thickness0.2mm0.3mm0.4mm (durable)

*50W exceeds industry benchmarks by 20%.

Supplier's note

  1. Technical Breakthroughs:

    • Dual-Band Flexibility: The Pro model’s 5GHz support enables 4x faster data rates than 2.4GHz-only antennas.
    • High-Power Tolerance: 50W input handles industrial IoT workloads 30% better than standard 30W models.
    • Conformal Design: FPC material reduces form factor by 25% compared to rigid PCB antennas.

  2. Version Selection Guide:

    • Base Model: Ideal for low-power IoT sensors or basic Wi-Fi modules.
    • Advanced Model: Best for smart home hubs and drones requiring 5GHz for reduced latency.
    • Pro Model: Choose for industrial routers or automotive systems needing 5GHz + 50W resilience.

With vertical polarization, you can ensure optimal signal alignment in vertical device orientations. With 50W power handling, you can support high-throughput industrial IoT deployments.

Frequently asked questions

  • Which PCB antenna model is best suited for ESP32-based IoT devices with limited space?

  • Why choose a PCB-based antenna over traditional wire antennas for internal device integration?

  • Can the 2.4GHz PCB antenna support both Wi-Fi and Bluetooth applications?

  • Does your PCB antenna offer customization for specific frequency ranges beyond 2400-2500MHz?

  • How does the FPC connector simplify PCB antenna installation in compact devices?

  • What makes your 2.4GHz PCB antenna suitable for high-interference environments?

  • Is the PCB material resistant to environmental factors like temperature changes or vibrations?

  • What is the maximum power handling capacity of your 2.4GHz PCB antenna?
