  • DRC 50 Pin Connector Engine Wiring Harness
DRC 50 Pin Connector Engine Wiring Harness

DRC 50 Pin Connector Engine Wiring Harness

$26.50-$29.50/ Piece|100 Piece/Pieces(Min. Order)

Customization:

Customized logo（Min.Order: 5000 pieces）
Customized packaging（Min.Order: 1000 pieces）
Graphic customization（Min.Order: 1000 pieces）
View product details

DRC 50 Pin Connector Engine Wiring Harness

Product overview

Core functionalities

Applicable scenarios

Unique advantages

  • High-Performance Electrical Connectivity: The DRC 50 Pin Connector Engine Wiring Harness is designed to handle high currents and voltages, enabling secure and reliable electrical connections in complex automotive engine systems.
  • Robust Locking Mechanism: Features a durable locking system to ensure stable connections even under dynamic conditions, such as vibrations in automotive or industrial environments.

Key features

  • 1. Durable Material Technology

    • With a corrosion-resistant plastic body, ensure environmental durability against moisture, temperature fluctuations, and harsh automotive environments.

  • 2. Secure Interactive Design

    • With a robust locking mechanism, guarantee stable connections even under vibrations or mechanical stress, preventing accidental disconnections in dynamic conditions.

  • 3. High-Performance Electrical Handling

    • With a 50-pin configuration and high current/voltage compatibility, support complex automotive systems requiring reliable power and signal transmission for multiple circuits.

  • 4. Modular Scenario Solutions

    • With a customizable modular design, adapt to diverse automotive applications by reconfiguring contacts and integrating seamlessly into various vehicle systems.

  • 5. Automotive-Grade Compliance

    • With automotive industry certification standards*, ensure safety, reliability, and compatibility with demanding vehicular and industrial use cases.

Product details

DRC 50 Pin Connector Engine Wiring Harness

The DRC 50 Pin Connector Engine Wiring Harness is a robust, high-performance solution designed for automotive and industrial applications. Featuring a durable plastic composite material, a 50-pin grid array, and a positive-locking mechanism, it ensures secure, reliable connections in harsh environments. Its modular design allows customization for diverse wiring needs, while its high-current and voltage handling capabilities make it ideal for complex systems requiring multiple signal and power pathways.

Technical specifications

FeatureSpecificationApplication Scenario
MaterialDurable plastic compositeAutomotive/industrial environments with temperature fluctuations and moisture exposure
Contacts50-pin grid arrayComplex automotive systems needing multiple circuits (e.g., engine management, sensor networks)
Locking MechanismPositive-locking designVibrating environments like engine compartments or machinery
Current/VoltageHigh current/voltage capacityHigh-power systems (e.g., electric vehicle battery interfaces, heavy machinery)
Modular DesignCustomizable contact configurationsCustom wiring solutions in hybrid/electric vehicles or specialized machinery

Customization guide

Adjustable contact configurations to meet specific cable and connector requirements in automotive systems.

Get inspired

The DRC 50 Pin Connector’s modular design and high-performance features make it a versatile choice for engineers and manufacturers. Whether you’re designing an electric vehicle’s engine harness or integrating sensors into industrial equipment, this connector ensures reliability under demanding conditions.

Choose your model

ParameterBase ModelAdvanced ModelPro Model
Current per Contact20A+25% (25A)+50% (30A)
Vibration Resistance10G+50% (15G)+100% (20G)
Operating Temp Range-20°C to 85°CExtended (-30°C to 105°C)Extreme (-40°C to 125°C)
Locking MechanismStandardEnhancedReinforced

Supplier's note

  1. Technical Breakthroughs:

    • The Pro Model’s 20G vibration resistance (double the industry standard) ensures stable connections in off-road vehicles and heavy machinery.
    • The 30A per contact capacity (50% higher than Base) enables powering high-demand engine components like turbochargers.
    • Extreme temperature tolerance (-40°C to 125°C) supports use in Arctic vehicles or desert-based industrial equipment.

  2. Version Selection Guide:

    • Base Model: Ideal for standard automotive applications (e.g., passenger vehicles) where moderate current and vibration are expected.
    • Advanced Model: Suitable for heavy-duty trucks or agricultural machinery needing enhanced durability and wider temperature ranges.
    • Pro Model: Best for extreme environments (e.g., mining equipment, electric vehicle charging systems) requiring unmatched reliability and power handling.

With the Pro Model’s reinforced locking mechanism, you can eliminate connection failures in high-vibration scenarios. Pair its 30A capacity with its extreme temp range to ensure seamless operation in polar or desert conditions. The Advanced Model’s 15G resistance and extended temp range make it perfect for commercial trucks facing varied climates.

Frequently asked questions

  • Which DRC 50 Pin Connector model is best suited for heavy-duty automotive applications?

  • How do I clean and maintain the DRC 50 Pin Connector to prevent corrosion?

  • Why is the DRC 50 Pin Connector made of durable plastic instead of metal?

  • Can the DRC 50 Pin Connector be customized for specific automotive systems?

  • Is the DRC 50 Pin Connector certified for automotive use?

  • How does the DRC 50 Pin Connector handle high currents in engine wiring?

  • Does the DRC 50 Pin Connector work in vibrating environments like engines?

  • Can I integrate the DRC 50 Pin Connector with different cable types?
