There are many different kinds of antenna circuit boards used for various applications and devices. Many factors should be considered, including the frequency range, usage, and space constraints. The most common types include the following.
A Dipole Antenna is an old antenna design that sends and receives radio waves. It consists of two conductors mounted parallel and insulated on the antenna circuit board.
The Dipole antenna is usually used short range in FM radio, television antenna, and Wi-Fi. Because of its simple design, it's easy to manufacture and is commonly found in many consumer electronic products.
A Monopole Antenna is a half-variant of the Dipole antenna. It consists of one conductor or rod and projects electromagnetic waves vertically from the ground.A PCB Monopole Antenna is often found in mobile phones, AM radios, GSM, and GPS because of its compact size.
A Patch Antenna, also known as a Microstrip or a Chip Antenna, is a small and compact antenna design made from a conductive metal (like copper) on insulating material (the circuit board). It provides a good balance between size and performance. It is also easy to mass-produce and use economically.
Due to its compact design, the patch antenna is suitable for mobile devices. It is found in GPS, satellite communications, and a variety of other wireless systems.
Loop Antennas are simple antennas consisting of a loop or coil of wire, with one of the major benefits being its compact size. It can also reduce noise and pick up the signal well in areas with above-ground interference.
There are mainly two types of Loop Antennas: small wire loop antenna and large magnetic loop antenna. Loop Antennas are primarily used in AM radio receivers, RFID systems, and near-field communication.
A Helical Antenna is a unique antenna that consists of a conductive wire shaped in the form of a helix or spring, designed to send or receive radio waves. Its compact design keeps it portable and easy to install. The antenna performs well:
Antenna circuit boards are incorporated into so many modern devices that provide wireless connectivity. They allow the device to send and receive signals.
A few important features sustainable of antenna circuit boards are:
The impedance of an antenna circuit board should match the device it is incorporated into to minimize power loss. This ensures the signals are efficiently transferred between the device (like a smartphone) and the antenna (like a PCB antenna).
Therefore, the circuit patterns used for the antenna and the connected devices are carefully designed and optimized to match their impedances. This avoids the energy wastage found in signals when the impedance is not well matched. This is particularly important in mobile phones, satellite systems, and long-range wireless communications.
The resonant frequency is the frequency at which the antenna efficiently radiates or receives signals. All good antennas should be designed to operate at a specific range of frequencies.
Everything will go wrong when the antenna is out of the designed resonant frequency. Signal loss, poor reception, and slow data transfer will be some of the likely results. Antenna circuit board designers ensure that the antenna is in resonance with the intended frequency range by closely following the operating frequency of the wireless communication system.
It refers to the shape or pattern formed by the distribution of the electromagnetic field. It determines how well the antenna can transmit or receive signals in various directions. It results from the directionality and gain of the antenna.
Ideally, antennas should be designed to radiate the signals uniformly within the desired area and minimize wastage or interference in unwanted regions (Radiation Pattern). Examples of common electronic devices with circular patterns include:
It refers to the orientation of the electromagnetic waves in the antenna. An PCB dipole antenna can be horizontally or vertically polarized. These two polarizations should match between the transmitting and receiving antennas to have a stable signal.
Modern antennas are linearly or circularly polarized. These are particularly important in devices like satellite systems, where the signal must be stable as the satellite moves across different antenna orientations.
It defines the shape and size of the antenna circuit board. It is important in devices where space is an issue. For instance, smartphones, wearables, and IoT devices. Such devices use compact, integrated antennas, although it compromises performance in some cases. Antenna circuit board designers prioritize antenna form factors and device ergonomics.
Antenna circuit boards are common in many consumer and industrial products because they help transmit and receive signals. Some commercial and industrial uses of antenna circuit boards include:
Antennas are used for cellular, Wi-Fi, GPS, and Bluetooth. Due to the small size, patch and monopole antennas are the most used PCB antennas.
Televisions, radios, and sound systems use different antennas to receive over-the-air signals and AM/FM radio, including Dipole, Loop, and Monopole Antennas.
IoT gadgets with wireless connectivity (like smart home devices, industrial sensors, and wearables) use Antenna Circuit Boards for different wireless protocols, such as Wi-Fi, Zigbee, LoRa, and Cellular. These antennas are compact and efficient.
Modern cars use antennas for various functions. For instance, GPS for satellite navigation, Bluetooth for hands-free calling and audio streaming, and cellular for mobile data connectivity. They use PCB antennas that include patch andhelical antennas.
Wireless communication systems and industrial monitoring sensors in industrial settings use Antenna Circuit Boards for different wireless standards, like Cellular, LoRa, and Zigbee.
Antennas are used for reliable long-distance communication. Helical and Patch Antennas are the most common types of antennas used for satellite and ground communications.
Radio Frequency Identification (RFID) and Near Field Communication (NFC) systems use Loop and Patch Antennas for inventory management, access control, and contactless payment systems. They help to quickly and accurately scan tags and make payments without holding anything.
These are all examples of commercial applications where Antenna Circuit Boards play a crucial role in enabling wireless connectivity. With the increasing demand for connected devices, Antenna designs will continue to evolve for improved performance.
There are several factors to consider when choosing an antenna circuit board:
It should be where the antenna should effectively work. No harm will be done if the range is slightly exceeded. The performance might not be optimal. The wireless communication system will malfunction if the antenna frequency is lower than the operating frequency. Select an antenna circuit board designed for a specific frequency range.
Low internal circuit board antenna failures can be caused by impedance mismatching. No energy is received or transmitted if this happens. For optimal energy transfer, choose an antenna circuit board whose impedance matches the device.
Choose the antenna type that perfectly does the job. A patch antenna is mostly suitable for compact, high-performance applications like smartphones, GPS devices, and satellite communications. A dipole and monopole antenna are best for simple and low-cost applications like basic radio and older mobile phones.
It is the orientation of the antenna. It must be the same between the transmitting and receiving antennas for optimal performance. Different Antenna circuit boards have a variety of polarization types: linear, circular, or elliptical. Select a polarization type that best suits the overall system requirements.
Good directivity ensures that the energy is focused within a desired area rather than in other random directions. This is particularly important in long-range communications. Omni-directional antennas would be ideal for devices that need signals in all directions (like Wi-Fi routers).
Conversely, directional antennas are suited for point-to-point communications (like satellite links). Choose an antenna circuit board developed with an ideal radiation pattern for the application.
Antenna circuit boards can be used indoors and temporarily outdoors. Their requirements for each location are completely different. Depending on if it's temporary or permanent, the durability level will change. For instance, outdoor antennas should be built with weather-resistant materials like stronger laminates and metals. Additionally, they should be able to withstand extreme temperatures, wind, and rain. Indoor antennas can be maintained easily. They are usually made of lighter and more fragile materials.
These two factors go hand in hand. Generally, larger antennas tend to offer better performance. This is because it provides better signal reception and transmission. But this is not always the case when space is an issue. Cost is another important factor. Various costs need to be considered, from production to maintenance. Cost goes hand in hand with quality. A good quality but expensive product will have the same performance as the cheap one, which will degrade faster.
A1. An antenna circuit board is a printed circuit board (PCB) that hosts an antenna used to send and receive electromagnetic signals. Various antennas designed for different applications can be integrated into the circuit board.
A2. A patch antenna is a small, flat antenna made of metal and foam. It sends and receives signals wirelessly in devices like GPS, Wi-Fi, and satellites because it is compact and efficient.
A3. It connects electric parts by providing signal paths like phones, computers, and satellites. It also helps devices communicate wirelessly by sending and receiving signals, for example, GPS and Wi-Fi. They are also used to receive TV and radio signals.
A4. The three main parts of an antenna are:
