Atv rear axle with reverse

Types of ATV Rear Axle With Reverse

An ATV rear axle with reverse is an important part of the all-terrain vehicle. It is a mechanical system that converts the quad bike's power to the rear wheels and allows the vehicle to move in reverse. The ATV rear axle with reverse improves handling, stability, and traction on rough roads. Below are the different types of ATV rear axle with reverse.

• ATV Solid Rear Axle With Reverse

  The solid rear axle is popular because of its strength and durability. The main shaft of the axle is strong and doesn't break down easily. The solid rear axle with reverse is great for off-road quad bike riders. The reverse gear is located on the transmission case. It allows the rider to shift into reverse easily and smoothly. The design of the solid rear axle with reverse is simple. It doesn't have a lot of parts that can break down. This makes it easy to maintain and repair when there is a mechanical problem. The solid rear axle is light in weight and helps to reduce the overall weight of the ATV.

• Independent Rear Suspension With Reverse

  The independent rear suspension with reverse offers better handling and stability on rough roads. Each rear wheel of the quad bike is connected to its own suspension system. This allows the wheels to move up and down without affecting each other. When a rider drives through a bumpy road or uneven ground, the independent rear suspension absorbs the shocks and impacts from the bumps. The reverse gear system is similar to the ATV rear axle. It allows the rider to shift into reverse smoothly and easily. The independent rear suspension with reverse is a great choice for quad bike riders who want comfort and control on rough roads.

• UTV Rear Axle With Reverse

  The utility task vehicle (UTV) is a larger and more powerful all-terrain vehicle compared to the ATV. The UTV rear axle with reverse is designed to handle the higher power and torque of the UTV. The UTV rear axle with reverse is suitable for off-road riding, especially when going through thick bushes or trees. The rear axle provides enough space for the rear wheels and brakes. This helps to improve the handling and braking ability of the UTV.

Specifications and maintenance of ATV rear axles with reverse

At the core of their operation, all ATVs have an axle. It is a critical component that connects the two wheels on one side of the vehicle. The strength and durability of the axle are crucial for off-road riding because it bears the weight of the ATV and supports the drive system.

Below are the key specifications of the ATV rear axle with reverse for buyers to take note of.

• Material: The material used to construct the rear axle is of great importance. Axles made from high-carbon steel are very common. High-carbon steel is known for its strength and durability, making it a good choice for ATV rear axles. Other materials like aluminum are not very common, but they are lighter and resistant to corrosion.
• Size: ATV rear axles with reverse come in different lengths. The length is measured from one end of the axle shaft to the other. The most common sizes are: 36.50 inches, 38.50 inches, and 40.50 inches. The size of the rear axle is determined by the type of ATV.
• Bearing cups: The bearing cups are located on the ends of the rear axle. They hold the bearings in place so that the rear wheels can spin smoothly without friction. The bearing cups are measured using the outer diameter (OD) and inner diameter (ID). Common sizes include: OD 2.25 inches and ID 1.75 inches; OD 2.50 inches and ID 2.00 inches; OD 3.00 inches and ID 2.50 inches.
• Splines: The spline is a toothed part of the axle that engages with the drive shaft or the differential. The number of teeth on the spline is usually specified. Common sizes include 24, 27, and 30 splines.

To keep the ATV rear axle with reverse in good working condition, buyers should communicate the maintenance needs of these products to end users. Here are some maintenance tips.

• Regular lubrication: Lubricating the rear axle regularly keeps it running smoothly. Lubrication also reduces wear and tear on the spline and bearing cups. Use high-quality grease to lubricate the spline and bearing cups. Make sure to clean the parts properly before applying the grease.
• Regular inspection: Check the rear axle for any signs of damage or wear and tear. Pay close attention to the spline and bearing cups. Look for cracks, rust, or pitting. Inspect the CV joints and boots for any signs of damage. Replace any damaged parts immediately.
• Clean the rear axle: The rear axle should be cleaned at regular intervals. Riding in dusty or muddy conditions causes dirt and debris to build up on the axle. This can lead to wear and tear over time. Use a pressure washer or a hose to remove any dirt or debris from the rear axle.
• Avoid overloading: Do not overload the ATV by carrying extra weight. Overloading puts extra strain on the rear axle and can lead to damage over time.
• Proper tire inflation: Make sure the rear tires are properly inflated. Check the tire pressure using a tire pressure gauge. Improper tire inflation can cause uneven wear on the rear axle.

How to choose ATV rear axle with reverse

Below are the factors that should be considered before purchasing an ATV rear axle with reverse

• Vehicle compatibility

  Buyers should ensure the ATV rear axle with reverse is designed for their ATV model. They should cross-check the brand, model, and year of their ATV to be sure it matches the axle specifications. This guarantees a precise fit and ideal performance. They should also consider the make of the ATV in relation to the rear axle. For instance, ATVs from reputable manufacturers like Polaris or Yamaha might need specific axles for each model.

• Quality and durability

  To avoid frequent replacements, buyers should invest in high-quality axles. The material of the axle is a good determinant of its quality. Axles made of heavy-duty steel or aluminum are more durable. They also provide better strength. Quality axles can handle rough terrains and extreme weather conditions.

• Length and width

  The length and width of the rear axle should be suitable for the ATV. Axles that are too long or too short cause handling issues and can get damaged easily. When determining the appropriate length, buyers should consider riding styles and preferences.

• Gear ratio

  Buyers should ensure the gear ratio of the axle matches their ATV's engine power and wheel size. A suitable gear ratio enhances torque and acceleration, improving overall ATV performance.

• Price

  Price should not be the first consideration when buying an ATV rear axle with reverse. Buyers should purchase quality axles from reputable suppliers on Alibaba.com. The axles come at different price points depending on quality, materials, and specifications.

• Warranty

  Buyers should check if the supplier offers a warranty for the ATV rear axle with reverse. A warranty is an assurance of quality. They should also check the warranty period and the terms and conditions.

• Reviews and recommendations

  Before buying an ATV rear axle with reverse, buyers should research online to see what other customers say about it. They should also ask their friends or other ATV owners for recommendations. This helps them find reliable suppliers and quality products.

How to DIY and Replace ATV Rear Axle with Reverse

• Prepare the ATV

  To replace the rear axle of an ATV with reverse gear, begin by ensuring that the ATV is on a flat surface. Then, turn off the engine and engage the parking brake. After that, the rear wheels should be removed, and the wheel lugs should be loosened with a wrench. Then, the ATV should be raised using a jack, and the ATV's rear end should be lifted and secured with jack stands.

• Drain the differential oil

  When replacing the rear axle of an ATV with reverse gear, after preparing the vehicle, the differential oil is drained. This is done by removing the differential drain plug situated on the bottom side of the differential. Once the plug is removed, the oil drains into a suitable container. Keep in mind that the differential oil may be warm shortly after operating the ATV, so take appropriate precautions to avoid burns or spills.

• Remove the old rear axle

  After draining the differential oil, the old rear axle is detached from the ATV. To do this, the U-joint straps are accessed by removing the plastic cover. Then, the U-joint straps are unscrewed, disconnecting the axle from the differential. After that, the axle shaft is pulled out of the wheel hub. This may require a slide hammer or other suitable tools. Once the axle shaft is detached from the wheel hub, the wheel hub assembly is removed from the suspension. The wheel hub is detached from the suspension. To do this, the wheel hub is unscrewed from the suspension. The wheel hub is detached from the suspension. To do this, the wheel hub is unscrewed from the suspension.

• Install the new rear axle

  Once the old rear axle has been removed, a new rear axle is installed. To do this, the new rear axle is lubricated with clean differential oil, and the axle shaft is inserted into the wheel hub. Then, the wheel hub assembly is reinstalled onto the suspension, and the U-joint straps are bolted down, securing the axle to the differential.

• Finish up

  After installing the new rear axle, the differential oil is refilled. This is done by removing the differential fill plug located on the top side of the differential. Then, clean differential oil is poured into the fill hole until it reaches the recommended level, and the fill plug is securely tightened. Finally, the plastic cover is reattached, securing it in place with the appropriate fasteners. The ATV is then lowered off the jack, and all maintenance tasks are complete.

Q and A

Q1: How do I know if an axle is compatible with a specific ATV?

A1: Compatibility information is usually found in the axle's specifications. It can also be found in the ATV's service manual. This includes the axle's length, spline count, and the differential type.

Q2: What's the difference between a heavy-duty and standard ATV rear axle?

A2: A standard axle is designed for regular use. On the other hand, a heavy-duty axle is built for tough terrains and increased loads. This makes it suitable for demanding applications. The heavy-duty axles are more robust. They have larger diameter shafts and more durable materials.

Q3: Can I upgrade to a heavy-duty rear axle for better performance?

A3: Yes, it's possible to upgrade to a heavy-duty axle. This upgrade can improve durability and performance, especially for towing or carrying cargo. However, it may require additional modifications to the ATV.

Q4: What materials are commonly used in ATV rear axles, and what are their advantages?

A4: Common materials are steel and aluminum. Steel is strong and durable. It is ideal for rough terrains. Aluminum is lightweight, which reduces the overall weight of the ATV. This makes it suitable for racing or sports activities.

Q5: Can I install a rear axle myself, or do I need professional help?

A5: An axle can be installed by following the manufacturer's instructions. The installation process is quite simple. However, if the process is complicated, professional help may be needed to ensure correct installation and alignment.
