Scratch testers are available in several types, and each type is dependent on the methods by which they conduct the scratch testing process.
These scratch testers include:
Scratch hardness testers
Scratch hardness testers are automatic scratch testers that assess the scratch resistance of coatings, paints, and other materials. These types of testers utilize a moving stylus over a coated surface at a set angle of inclination. Also, to evaluate the resistance of the surface to scratched under the weight of the stylus. The result that is achieved from the operation of this kind of tester is a measurement of depth or visible damage that is recorded automatically.
Crosshatch Adhesion testers
Crosshatch adhesion testers perform scratch tests to evaluate the adhesion strength of the coating to substrate materials. Such testers draw a hatch pattern of predetermined mX squares and fins on the coated surface to assess how well the coating adheres to the substrate beneath it. After the crosshatch cut, the tester applies a controlled tape pull to measure adhesion by examining the amount of coating that is chipping, peeling, or flaking.
Pencil hardness scratch testers
This is where the pencil hardness scratch testers come into play. These testers, which often comply with ASTM standards, use pencils of varying hardness grades to determine the scratch resistance of the material. An automated scratch pencil hardness tester works a pencil scribed on a surface, measuring the force required to scratch the surface. Then it records the results as the pencil's hardness value.
Gradual load scratch testers
Unlike the previously mentioned testers, gradual load scratch testers evaluate scratch resistance by applying incremental weights to a scratching implement. This kind of tester provides a more detailed analysis of an optimal scribed surface as well as loads scribed in a controlled manner. Gradual load testers are used when there is a need for quantitative data on scratch resistance, usually in compliance with international standards. Also, these testers are useful for coatings and materials that are likely to be affected by varying degrees of pressure in actual usage.
Automotive
In the automotive industry, automatic scratch testers are used to assessing the durability of paints and protective coatings on vehicles. The scratch resistance data obtained ensures that automotive finishes can stand up to environmental elements and physical wear during usage. Thus, leading to the enhancement of the vehicle's appearance and corrosion protection.
Electronic goods
Automatic scratch testers have their place in the electronics industry, especially in testing the durability of screens, casings, and other components. These testers, by evaluating the scratch resistance of different materials, help improve the design of smartphones, tablets, and other electronic devices to be more resistant to damage. This not only enhances the practical appeal of the product to the customer but also reduces costs incurred by providing products with higher durability.
Consumer goods
Coatings, finishes, and other materials used in household goods, furniture, and appliances are among the things that undergo testing using automatic scratch testers in this industry. For example, in the paints and coatings industry, scratch testers are used to ensure a higher level of paint quality by making it less susceptible to scratches and blemishes through the study of scratch resistance. This leads to the development of products that provide longer aesthetic and functional values and to the satisfaction of the customer.
Construction industry
Automatic scratch testers in this industry contribute majorly to evaluating the performance of building materials such as glass, tiles, and marble. Testers help manufacturers develop and supply surfaces that are less prone to scratching during installation and maintenance processes. This leads to improved material durability and lower costs spent on repairs and replacements.
Industrial machinery and equipment
In this industry, automatic scratch testers are used to coatings and finishes used on machinery parts and equipment. These testers ensure that the coatings applied to parts can withstand the harsh operating conditions, resulting in the prevention of rust and reduced maintenance costs. Thus, enhancing the reliability and lifespan of the products and at the same time ensuring safety.
Load range
The load range (or weight application range) of automatic scratch testers varies from one tester to the next. Some testers have a large load range because they are suitable for different materials, whether they be soft ones like plastic or hard ones like metal. This adaptability ensures the tester gives accurate results by mimicking real-life conditions.
Scratch speed
Scratch speed refers to the speed at which the scratching tool or stylus moves across the material surface. Depending on the nature of the material being worked on, variable speeds are used to imitate different operational conditions. Usually, scratch speeds are in millimeters per second, which means that the tester has to be very accurate and quick.
Dimension of scratch
This dimension refers to the parameters or dimensions of the scratch mark incorporated on the surface of a material under test. Usually, these parameters or dimensions are predetermined and defined by the user, and they depend on the type of test that is being called for and the requirements of the industry. Hence, they may range from fine crosshatch patterns to broader and deeper scratches.
Working temperature
Scratch testers have a working temperature specification that is valid and essential for processes where temperature control is critical. These testers work within specified temperature ranges to reduce or eliminate the possibility of being affected by variations in temperature on material properties. Usually, the temperatures would be within room temperature and a few hundred degrees Celsius, and this largely depends on the material under examination.
Control system
Automatic scratch testers possess several control systems, usually automated by computer, in which the scratch parameters are set, the operation is monitored, and data are collected. Often, these systems are operable through a user-friendly interface, like other industrial equipment that employs the Windows-based application
Installation of an automatic scratch tester takes the following procedure.
Placement and leveling
The very first thing that needs to be done is to find a proper place for the scratch tester, a flat and steady surface where it won't wobble or shake. The stability of the device can affect its performance, so you have to ensure that it is appropriately leveled using the feet adjustment.
An electrical power supply connection
Scratch testers, as their name implies, require an electrical connection to operate, so the power requirements must be connected. This is usually done via standard power outlets while the users ensure that voltage levels are compatible with the device to avoid damage.
Installation of software
If the scratch tester is computer-controlled, the corresponding application software has to be installed on the computer. In most cases, this is done using the provided installation media or downloading it from online sources. The users must make sure that the software is compatible with the model of scratch testers in use.
Calibration
Just after the completion of the setup, the last stage is to perform calibration. Scratch testers have to be calibrated in order to provide precise load, depth, and speed for the testing operation. This may involve the adjustment of several internal parameters so that they correspond to a particular standard.
The following describes how automatic scratch testers are used.
Preparation of the sample
The sample, which should be a material or specimen, undergoes the preparation process before it is placed on the testing platform. This sample should be of a size that is comfortable to handle and representative of the material to be worked on.
Setting parameters
Once the sample is prepared, operating parameters such as load, speed, and scratch depth are input into the scratch test software. Those parameters should be within the scope of the test to be done, whether they are industry standards or specific to the company's internal working procedures.
Initiating the test
Upon parameters set, the user will start the test from the software interface, and the automatic scratch tester will perform the scratching. During this phase, the testers will automatically apply loads, move at designated speeds, and scratch to desired depth without any manual help.
Monitoring
Generally, while the scratch testing is in progress, it is the responsibility of the user to carefully monitor the automatic scratch tester for the purpose of ensuring everything goes well. The operator also needs to check for error messages and ensure no abnormalities arise. Automatic testers have been programmed to report real-time data, so they simplify this phase of monitoring.
Data recording and analysis
The best part about performing the scratch tests using these testers is that the data recorded is comprehensive and precise. The recorded data is then analyzed to derive relationships between the load applied and other parameters, leading to some performance or quality indices required to evaluate the material or surface used.
Use of testers according to manufacturers directives
Consistent and reliable results come from using scratch testers according to the manufacturer's guidelines on functionality and features. At this stage, no important aspects that relate to the operations, maintenance, or limitations of the automatic scratch testers should be overlooked.
Creating stable working environments
Avoiding fluctuations in load, temperature, and other parameters that may affect test results requires ensuring that the testing environment is stable. Controlling environmental factors, such as humidity and temperature, is critical, especially in sensitive materials.
Regular examination and calibration
The performance of scratch testers can be affected by wear and tear, so it is recommended that automatic scratch testers undergo assessment and calibration regularly. It is recommended that users formulate a specific routine schedule for testing calibration and checking to improve the accuracy of the results of any testing operation.
Proper protective equipment
Users of these testers should be equipped with appropriate protective equipment. This is because exposure to certain materials being worked on can be harmful or dangerous. Hence, ensure protection against chemicals and particles released during the test.
Examination of materials prior to testing
Sometimes, materials contain chemicals or substances in them that can be harmful to a person's health, and that's why it is important to assess those materials before the start of automatic scratch testing. If such a situation arises, there is a need for avoidance or minimization of direct contact with such materials.
Emergency protocols
Emergency protocols involve preparation for any possible accidents or exposures is very important to well-defined procedures in case of exposure to hazardous substances. Having first aid equipment at hand and knowing how to use it can improve the outcomes in such situations.
A1.An automatic scratch hardness tester is a device used to measure the scratch resistance of a given material, coating, or surface. This instrument uses a sharpened stylus that is pulled over a surface at a uniform rate while applying a specific amount of pressure. The main task performed by the scratch hardness tester is to observe how deeply the stylus cuts into the surface. This creates a numerical value called scratch hardness, which signifies how well the surface can resist an attempt at scratching or scuffing. Henceforth, automatic means that the whole process of testing requires no manual intervention because it's a machine operation with precision and efficiency.
A2.Scratch tests are performed to evaluate the scratch resistance or durability of a material or surface. Basically, it involves the measurement of the depth of the scratch that was made on the surface by either using a sharp object or an indenter under a specific force. The depth of the scratch gives the scratch resistance of the surface, and greater depth indicates that the surface is less rough and scratch resistant. These tests are widely used in many industries, such as automotive, electronics, and manufacturing, to determine which materials are best suitable for coatings, finishes, and other applications where the end product is vulnerable to scratching.
A3.Scratch tests are classified into two categories: the mechanical scratch test and the adhesion scratch test.The mechanical scratch test usually uses mechanical means, such as a scratch stylus, to make a controlled scratch on the material surface. While the adhesion scratch test is simply a test to scratch a notch or groove into the material surface and observes the adhesion of the material to the substrate.
A4.Pencil hardness is the ability or capacity of a material or surface, mainly a coating or a finish, to resist an attempt at scratching by a pencil lead. This test involves using pencils with different leads of hardness. A scratch is made on the surface, and a force is applied to try to blend the pencil lead into the surface. The degree of pencil hardness, where no scratching occurs, is recorded. This defines scratch resistance.
A5.Put simply, scratch resistance refers to the ability or capacity of a material to resist an attempt at scratching. It's a typical property of various materials, such as metals, plastics, and glasses, especially in coatings. It is, therefore, a very important consideration in the design and selection of materials that will be exposed to wear and tear. Common applications include the scratch resistance of surfaces, such as smartphone screens and automotive paints.
